Fuse Panel Indicators            The Panteras electrical system is monitored on the input power to the fuse panel before distribution. Since the Pantera ignition switch is notorious for failure these indicators are helpful for diagnostics.  "Accessories" position green indicator for the key switch  power “ON”  "Ignition" position green indicator for the key switch power “ON”. Each fuse has a red LED indicator for "OPEN" fuse condition.
HOME HOW TO ORDER RECOMMENDATIONS
de Tomaso Pantera Fuse Panel
PRODUCTS
For your Metal Mistress
> 12 ATO blade fuses plus 2 additional ATO fuses for the power windows, this eliminates the fuse box with 2 fuses mounted on the wheel housing. A total of 14 ATO fuses in the same footprint as the original 12 fuse panel. > ATO Fuse Panel includes fuse panel with fuses installed. > Rugged open frame construction to dissipate heat, built with high quality non-flammable materials, aluminum, copper, brass, glass impregnated fiber board. Note, fuse panels generate heat, this fuse panel is NOT assembled with glue or adhesives as these will soften or melt. > Mounting foot print is identical to the factory and utilizes the factory 5mm mounting screws and plastic insulation shim. > Electronic noise suppression devices for each fused circuit to minimize electrical noise from car stereo systems. > Quick disconnect terminals are labeled with wire color and function to help de-bug wiring problems. > ATO fuses are labeled on the fuse panel with circuit number and current rating. > Each fuse has a red LED indicator for "open" fuse condition. (note that the protected load  must be active or "ON" for the LED to operate) > Quick disconnect terminals are geometrically positioned similar to the factory fuse panel, transferring one wire at a time to minimize installation problems. "EXTRA" terminals marked for an additional accessories. > ATO automotive fuses were designed for the automotive industry and are readily available in Europe, Canada and U.S.A.
CRITICAL SUPPORT CONTROLS H-P IMPROVED SAFETY ELECTRONIC IGNITION FUSE PANEL IGNITION SWITCH HEADLIGHT / MOTOR RAD FAN CONTROLLER RADIATOR AND FANS PARKING BRAKE CONTROL CONSOLE INTERFACE AIR CONDITIONING ROCKER SWITCHES WINDOW SWITCHES DUAL USB CHARGER LED GAUGE LAMP LED DOME, LED FOOTWELL LED DOOR COURTESY LED DOOR JAMB LAMP LED LICENSE PLATE LAMP LED SIDE MARKER LAMPS LED SIGNAL LIGHTS LED TAILLIGHTS GROUP4 LED LIGHTS LED SIGNAL FLASHER ALTERNATOR KIT ELECTRICAL PRODUCTS ELECTRICAL COMPONENTS WIRE HARNESS
Fuse Panel Part # FP-01 Price $295.00 USD Glove Box set of ATO fuses: (6) 7.5 Amp (2) 15 Amp (2) 25 Amp (4) 30 Amp Part # F-ATO Price $6.00 USD
